Key Features:
1. Efficient combustion system: adopts single vertical chain grate design, combustion efficiency is more than 86%, equipped with secondary air intake system, to achieve full combustion of fuel, exhaust temperature is less than 140℃, small heat loss.
2. Environmental protection and energy saving: in line with the country's most stringent environmental protection standards, soot emission is less than 20mg/m³, nitrogen oxide emission is less than 150mg/m³, high fuel efficiency, operation cost is 40% lower than that of fuel oil boiler.
3. Intelligent control system: automatic control with PLC+ touch screen, automatic ignition, constant temperature control and fault alarm function. Remote monitoring system can be selected to realize intelligent management.
4. Safe and reliable: multiple safety protection: water shortage protection, over temperature protection, flame out protection, boiler body adopts Q245R high quality boiler steel, design life more than 12 years.
Core Selling Points:
1. Strong adaptability to fuel: can burn all kinds of biomass particles, wood blocks, straw and so on.
2. Low operating cost: fuel cost is only 1/3 of gas boiler.
3. High degree of automation: automatic feeding, slag removal, reduce labor costs.
4. Environmental protection standards: easily meet the requirements of various places.
5. Easy installation: complete installation, on-site installation quickly.
Typical applications:
1. Central heating (neighborhoods, schools, hospitals).
2. Industrial hot water (textile, food, chemical).
3. Agricultural greenhouse heating.
4. Hot water supply in bathhouse.
Product spotlights:
Feature highlights:This Horizontal Fully Automatic Steam Boiler is made of high-quality Carbon Steel and Stainless Steel, ensuring durability and efficiency. It features a Fire Tube structure with a thermal efficiency of ≥98%, making it highly energy-efficient. The boiler supports multiple fuels including Biomass, firewood, and coal, and operates at a steam temperature of ≤194℃ with a rated pressure of 1.25Mpa. Equipped with a PLC control system and touch screen interface in English, it is easy to operate and maintain. The product is CE certified, ensuring compliance with EU safety standards and providing market access for buyers.
Supplier highlights:This supplier is both a manufacturer and trader, cooperates with Fortune 500 companies and excels in quality control, offering full customization and design-based services. Main export countries include the United States, Indonesia, and Zimbabwe with a positive review rate of 100.0%.
Key attributes：
key selling points | Automatic, Easy To Operate | Material | Stainless Steel, Carbon Steel |
Fuel | Biomass, firewood, coal | pressure | Low Pressure |
structure | Fire Tube | output | Steam |
usage | Industrial | type | Natural Circulation |
Style | Horizontal | Warranty | 1 Year |
core components | Screw, Pump, Gear, Motor, Pressure vessel | machinery test report | Provided |
video outgoing-inspection | Provided | Weight (KG) | 10000 |
place of origin | Henan, China | brand name | Yin Xing Boiler |
dimension(l*w*h) | Refer To Models | Product | Fully automatic biomass hot water boiler |
Thermal efficiency | ≥ 98% | Rated pressure | 1.25Mpa |
Rated evaporation capacity | 1t/h---4t/h | Control System | PLC, Touch Screen, English Language |
Installation Method | Free-Installation (No Need Assembly) | Applicable Fuel | Biomass, firewood, coal |
Steam Temperature | ≤194℃ (accept customization) | Design advantage | Three Return Furnace, Threaded Smoke Pipe, Self-dusting Function |
Application Field | Textile, Garment, Food & Beverage, Chemical & Oil, Washing, Paper | ||
Technical Parameters：
